A1FM14 Walkway Mesh Grid Walk is a heavy-duty expanded metal mesh designed for industrial flooring, walkways, ramps, and access platforms. Manufactured from mild steel or hot dip galvanised steel, it delivers excellent strength, slip resistance, drainage, and durability. Common applications include walkway mesh, industrial flooring mesh, grid walk mesh, trailer ramp mesh, skeeter ramp mesh, and truck ramp mesh.
Expanded metal mesh provides a durable, cost-effective solution that combines high load-bearing capacity with excellent airflow and drainage, making it suitable for both indoor and outdoor environments.
| Weight | 14.4kg/SQM |
| Dimensions | N/A |
| Material | Mild Steel or Hot Dip Galvanised |
| Unit of Sale | Sheet |
| Material Thickness (mm) | 5mm |
| Sheet Size LWM x SWM (mm) | 750X3000mm, 900X3000mm, 1200X3000mm |
| LWM (mm) | 135mm |
| SWM (mm) | 45mm |
| LWO (mm) | 96mm |
| SWO (mm) | 32mm |
| Strand Width (mm) | 8mm |
Available in mild steel, hot dip galvanised steel, aluminium, and stainless steel, expanded metal mesh can be supplied in various sheet sizes, strand widths, and opening patterns to suit your project requirements. Custom sizes and finishes are also available.
Material Finish: Mill finish/off the machine (uncoated or direct from the factory & will have residue from manufacture)
We recommend the product be cleaned, coated and finished as appropriate for the application.
